1N5822
1N5822 is a Schottky diode in DO-41 package.
PackageDO-201AD
Reverse Voltage (VR)40V
Forward Current (IF)3A
TypeSchottky Rectifier Diode
ConfigurationSingle Diode
Forward Voltage (VF)0.525V Max. @ 3A
Product Overview
1N5822 is a Schottky diode in DO-41 package.
Specifications
Key electrical, package, and sourcing parameters for quick engineering review.
| Part Number | 1N5822 |
| Brand | CNCHIPDEPOT |
| Package | DO-41 |
| Category | Discrete Semiconductor Products - Schottky Rectifiers |
| Type | Schottky Rectifier Diode |
| Configuration | Single Diode |
| Package / Case | DO-201AD, Axial |
| Supplier Device Package | DO-201AD |
| Mounting Type | Through Hole (THT) |
| Technology | Schottky |
| Voltage - DC Reverse (VR) | 40V |
| Current - Average Rectified (IO) | 3A |
| Forward Voltage (VF) | 0.525V Max. @ 3A |
| Reverse Leakage Current (IR) | 2mA @ 40V |
| Speed | Fast Recovery ≤500ns, >200mA |
| Operating Junction Temperature | 150°C Max. |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Obsolete |
| RoHS Status | RoHS3 Compliant |
| REACH Status | REACH Unaffected |
| Product Type | Schottky diode |
